Shelly DALI Dimmer Gen3

Physical

Size (HxWxD):

42x37x17 mm / 1.65x1.46x0.66 in

Weight:

18 g / 0.63 oz

Screw terminals max torque:

0.4 Nm / 3.5 lbin

Conductor cross section:

0.5 to 1.5 mm² / 20 to 16 AWG (solid, stranded, and bootlace ferrules)

Conductor stripped length:

5 to 6 mm / 0.20 to 0.24 in

Mounting:

In-wall, suspended ceilings

Shell material:

Plastic

Shell color:

Green

Environmental

Ambient working temperature:

-20 °C to 40 °C / -5 °F to 105 °F

Humidity:

30 % to 70 % RH

Max. altitude:

2000 m / 6562 ft

Electrical

Power supply:

110 - 240 VAC ±10% 50/60Hz

Power consumption:

< 2 W

Neutral not needed:

No

Output circuits ratings

Bus power supply

Guaranteed 10mA (up to 5 DALI control gear units), Short circuit current < 35 mA

Bus voltage

16V nominal

Sensors, meters

Internal-temperature sensor:

Yes

Radio

Wi-Fi

Protocol:

802.11 b/g/n

RF band:

2401 - 2495 МHz

Max. RF power:

< 20 dBm

Range:

Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors
(Depends on local conditions)

Bluetooth

Protocol:

4.2

RF band:

2400 - 2483.5 MHz

Max. RF power:

< 4 dBm

Range:

Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors
(Depends on local conditions)

Microcontroller unit

CPU:

ESP32-C3 Shelly

Flash:

8 MB

Firmware capabilities

Schedules:

20

Webhooks (URL actions):

20 with 5 URLs per hook

Scripting:

Yes

MQTT:

Yes

Encryption:

Yes, TLS 1.2

N

Neutral terminal

N

Neutral wire

L

Live (110-240 V~) terminal

L

Live (110 - 240 V~) wire
50-60 Hz

Out

Dali dimmer load output

S1, S2

Switch input terminals

DA+

Dali interface positive terminal

DA-

Dali interface negative terminal
