0.5 to 4 mm² / 20 to 11 AWG (solid, stranded, and bootlace ferrules)
Conductor stripped length:
6 to 7 mm / 0.24 to 0.28 in
Mounting:
Wall console
Shell material:
Plastic
Shell color:
Red
Terminal Color
Black
Environmental
Ambient working temperature:
-20 °C to 40 °C / -5 °F to 105 °F
Humidity:
30 % to 70 % RH
Max. altitude:
2000 m / 6562 ft
Electrical
Power supply:
110-240 V~
24-30 V⎓
Power consumption:
< 1.2 W
External protection:
Cable protection switch in accordance with EN60898-1 (tripping characteristic B or C, max. 16 A rated current, min. 6 kA interrupting rating, energy limiting class 3)
Output circuits ratings
Max. switching voltage:
240 V~
30 V⎓
Max. switching current:
16A (240 V~)
10A (30 V⎓)
Sensors, meters
Internal-temperature sensor:
Yes
Voltmeter (AC):
Yes
Ammeter (AC):
Yes
Radio
Wi-Fi
Protocol:
802.11 b/g/n
RF band:
2401 - 2483 МHz
Max. RF power:
< 20 dBm
Range:
Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions)
Bluetooth
Protocol:
4.2 with BLE
RF band:
2400 - 2483.5 MHz
Max. RF power:
< 4 dBm
Range:
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions)
